Inputs
• S/PDIF coaxial RCA @ 75 Ohms 8-96kHz, S/PDIF Toslink 8-96kHz
• ADAT optical 16/20/24-bit 44.1/48kHz Type I/II
• EXT: 8-96kHz, 16/24-bit I2S/LJ/RJ/AUTO, x256/384Fs, mini HDMI 6-line LVDS
• USB: 2.0 8/16/32/44.1/48/88.2/96kHz ±5%
• AUX: ±10dB adjusted unbalanced stereo, 1dB step, 3.5mm jack
Outputs
• RCA: -10dBV nominal, +6dBV max, ultra low impedance
• Headphones: 3.5mm jack, 250mW @ 30 Ohms
Control
• Multifunctional pushbutton encoder
Technical charachteristics
• DACs: Burr Brown PCM63P-K/PCM1704U-K, Analog Devices AD1862N-J
• DAC word lenght: 20-bit (ESD-6300, ESD-1862), 24-bit (ESD-1704)
• DAC quantity: 2, left/right channel
• Frequency response: 5-22kHz ±0.1dB
• Sample rates: 8/16/32/44.1/48/88.2/96kHz ±10%
• Digital Filter word lenght: 24-bit
• Input word lenght: 16/18/20/24-bit, all inputs
• THD+N: -92dB (ESD-6300), -118dB (ESD-1704), -96dB (ESD-1862)
• Dynamic range: 105dB (ESD-6300), 112dB (ESD-1704), 100dB (ESD-1862)
• Interchannel separation: -120dB
• Power supply: 5VDC @ 650mA
• Dimensions (W x H x D): 96 x 34 x 140
• Weight: 450g
• S/PDIF coaxial RCA @ 75 Ohms 8-96kHz, S/PDIF Toslink 8-96kHz
• ADAT optical 16/20/24-bit 44.1/48kHz Type I/II
• EXT: 8-96kHz, 16/24-bit I2S/LJ/RJ/AUTO, x256/384Fs, mini HDMI 6-line LVDS
• USB: 2.0 8/16/32/44.1/48/88.2/96kHz ±5%
• AUX: ±10dB adjusted unbalanced stereo, 1dB step, 3.5mm jack
Outputs
• RCA: -10dBV nominal, +6dBV max, ultra low impedance
• Headphones: 3.5mm jack, 250mW @ 30 Ohms
Control
• Multifunctional pushbutton encoder
Technical charachteristics
• DACs: Burr Brown PCM63P-K/PCM1704U-K, Analog Devices AD1862N-J
• DAC word lenght: 20-bit (ESD-6300, ESD-1862), 24-bit (ESD-1704)
• DAC quantity: 2, left/right channel
• Frequency response: 5-22kHz ±0.1dB
• Sample rates: 8/16/32/44.1/48/88.2/96kHz ±10%
• Digital Filter word lenght: 24-bit
• Input word lenght: 16/18/20/24-bit, all inputs
• THD+N: -92dB (ESD-6300), -118dB (ESD-1704), -96dB (ESD-1862)
• Dynamic range: 105dB (ESD-6300), 112dB (ESD-1704), 100dB (ESD-1862)
• Interchannel separation: -120dB
• Power supply: 5VDC @ 650mA
• Dimensions (W x H x D): 96 x 34 x 140
• Weight: 450g
